SPB-PIM GW has two functional components:
SPB-PIM Gateway Controller Nodes (Controller), which are used for multicast source discovery.
SPB-PIM Gateway Nodes (Gateway), on which the SPB-PIM Gateway interfaces reside.
Note
The Controller and Gateway can reside in a single node.
The following figure shows the SPB-PIM GW components.
